Driving method:

Digital control servo motor

Cutting method:

Media-moving method

Loadable material width:

2 to 27-1/2 in. (50 to 700 mm)

Maximum cutting area:

Width: 22.9 in (584 mm)

Length: 984.25 in (25000 mm)

Acceptable tool:

Special blade for CAMM-1 series

Maximum cutting speed:

19.69 in/s (500 mm/s) (all directions)

Cutting speed:

.4 in to 19.69 in/s (10 to 500 mm/sec) (all directions)

Blade force:

30 - 350 gf

Mechanical resolution:

0.000492 in./step (0.0125 mm/step)

Software resolution:

0.000984 in./step (0.025 mm/step)

Distance accuracy:

Error of less than ±0.2 % of distance traveled, or ±0.1 mm, whichever is greater

Repetition accuracy:

±0.1 mm or less

Alignment accuracy for printing and cutting when loading printed material:

±1 mm or less for movement distance of 210 mm or less in material-feed direction and movement distance of 170 mm or less in width direction (Excluding effects of printer and/or material)

Interface:

USB interface (compliant with Universal Serial Bus Specification Revision 2.0 Full Speed, Connecting Multiple Units)

Re-plot memory:

2MB

Instruction system:

CAMM-GL III

Power supply:

Dedicated AC adapter

Input:

AC 100 to 240 V ±10 % 50/60 Hz 1.7 A

Output:

DC 24 V, 2.8 A

Power consumption:

Approx. 30 W (including AC adapter)

Acoustic noise level during operation:

70 dB (A) or less (according to ISO 7779)

Acoustic noise level during standby:

40 dB (A) or less (according to ISO 7779)

Dimensions:

33.5 in (W) × 12.2 (D) × 9.17 (H)
[851 (W) x 310 (D) x 235 (H) mm]

With stand 33.5 in (W) X 12.2 (D) X 40.75 (H)
[851(W) X 310 (D) X 1035 mm (H)]

Weight:

29.77 lbs. [13.5 kg]

With stand 58 lb. [26 kg]

Packaging size:

38 (W) x 17.7 (D) x 15.3 (H) in.

[975 (W) x 450 (D) x 390 (H) mm]

Packaging weight:

39.7 lb. (18 kg)

Environment:

Temperature: 5 to 40°C (41 to 104°F), humidity: 35 to 80 % (no condensation)

Included items:

AC adapter, power cord, blade, blade holder, roller base, alignment tool, USB cable, Set Up guide
